Control Techniques Digitax ST - Page 193

Parameter
structure
Keypad and
display
Parameter x.00
Parameter
description format
Advanced parameter
descriptions
Serial comms
protocol
Electronic
nameplate
Performance
Menu 17
Digitax ST Advanced User Guide 193
Issue Number: 1 www.controltechniques.com
The priority levels of different tasks may be changed with this parameter. The parameter is accessed in a bit-wise manner:
Specifies the DPL program line number that caused a run-time error. This is valid only when:
• The user program has been compiled with the debug option set.
• The error is one that can be generated by user code, for example divide by zero (50) or parameter does not exist (41).
If both of these conditions are not met, the line number parameter will display zero (0).
This parameter is available for the user to put in an ID code of their program. This may, for example, be the software version number. Use the function
block SETUSERID() to write to this parameter.
When a run-time error occurs the error number is placed into this parameter.
For more information, see Section 11.1 Run-time Errors in the SM-Applications Modules and Motion Processors User Guide.
*See trip SLX.Er, Automation (I/O Expansion) module category on page 134.
17.44 Task priority level
Digitax ST Variant Indexer, Plus
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 to 255
Default 0
Update rate 4ms write
Bit Value Meaning
0
0 CTNet task priority is higher than Pos tasks priority.
1
CTNet task priority is lower than Pos tasks priority. This will reduce the
jitter of the POS tasks but could lead to the CTNet task being starved
1
0 Inter-option communication task priority is higher than the POS tasks.
1 Inter option communication task priority lower than the POS tasks.
2
0 Turbo CTNet Disabled
1 Turbo CTNet Enabled
17.48 DPL line number in error
Digitax ST Variant Indexer, Plus
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 1
Range 0 to 2,147,483,647
Default 0
Update rate 4ms write
17.49 User program ID
Digitax ST Variant Indexer, Plus
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range -32,767 to +32,768
Default 0
Update rate 4ms write
17.50 Motion Processor error status*
Digitax ST Variant Indexer, Plus
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 1
Range 0 to 255
Update rate 4ms write
