Control Techniques Digitax ST - Page 192

Menu 17
Parameter
structure
Keypad and
display
Parameter x.00
Parameter
description format
Advanced parameter
descriptions
Serial comms
protocol
Electronic
nameplate
Performance
192 Digitax ST Advanced User Guide
www.controltechniques.com Issue Number: 1
This parameter displays the current Motion Processor’s synchronization status.
When this parameter is ON (1), the voltage on the Motion Processor digital input 0 (zero) is passed through to the drive’s internal Freeze line. This
can be seen by other classes of SM-Solutions modules. For further information on Freeze input, refer to Chapter 8 Freeze and Marker in the SM-
Applications Modules and Motion Processors User Guide.
When this parameter is set to zero a freeze occurs on the rising edge of the freeze signal. When it is set to 1 a freeze occurs on the falling edge of
freeze signal. For further information on Freeze input, refer to Chapter 8 Freeze and Marker in the SM-Applications Modules and Motion Processors
User Guide.
When this parameter is set to zero the Motion Processor will freeze data when it sees a rising edge of a freeze pulse from the drive. When it is set to
a 1 the Motion Processor will freeze data when it sees a falling edge of a freeze pulse from the drive. For further information on Freeze input, refer to
Chapter 8 Freeze and Marker in the SM-Applications Modules and Motion Processors User Guide.
17.39 Inter-UT70 synchronization status
Digitax ST Variant Indexer, Plus
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 to 3
Default 0
Update rate 4ms write
Synchronisation
Status
Status
0
The synchronisation master request is zero or another Solutions
Module is synchronisation master.
1 The Motion Processor is synchronisation master.
3
The Motion Processor is synchronisation master, but the
synchronisation frequency is out of specification or not present.
17.40 Inter-UT70 master transfer mode
Digitax ST Variant Indexer, Plus
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 to 10
Default 1
Update rate 4ms write
17.42 Freeze main drive position
Digitax ST Variant Plus
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range OFF (0) or On (1)
Default OFF (0)
Update rate 4ms write
17.43 Freeze invert
Digitax ST Variant Indexer, Plus
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range OFF (0) or On (1)
Default OFF (0)
Update rate 4ms write
