The status of the CTNet network is displayed in the CTNet diagnostic parameter. When the Motion Processor is communicating successfully on the
CTNet network the number of messages per second is displayed.
If this parameter is set, then if the user attempts to download a new user DPL program or operating system to the Motion Processor and the drive is
enabled the download will be rejected and a run-time trip 70 will occur, if the global run-time trip parameter (Pr 17.14) is set.
Since downloading stops normal operations of the Motion Processor it may be considered unsafe to do this if the drive system is running, therefore
setting this parameter will prevent downloading under this condition.
When this parameter is 0 the drive will trip with runtime error 81 if an APC non-recoverable error occurs, such as use of an uninitialized CAM function.
When this parameter is 1 the drive will not trip when an APC non-recoverable error occurs
Display Value Description
Disabled 0 No event task scheduled
Event 1 EVENT task scheduled
Event1 2 EVENT1 task scheduled
Event2 3 EVENT2 task scheduled
Event3 4 EVENT3 task scheduled
17.36 CTNet diagnostic parameter
Digitax ST Variant Plus
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Update rate 4ms write
Table 5-13 CTNet diagnostics
Pr 17.36 Status Description
>0 Network Healthy
Indicates the number of messages per second be processed every
second.
0
Network Healthy,
No Data Transfer
The low-level token ring has been established and is active, but the
node is not receiving any CTNet data messages.
-1 RECON A network reconfiguration has been detected.
-2 Initialisation Error
The Motion Processor was unable to configure the CTNet interface.
Check that the node address and data rate are set correctly.
-3 MYRECON The Motion Processor forced a CTNet network reconfiguration
17.37 Reject download if drive enabled
Digitax ST Variant Indexer, Plus
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range OFF (0) or On (1)
Default OFF (0)
Update rate 4ms write
17.38 Do not trip drive on APC run-time error
Digitax ST Variant Indexer, Plus
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range OFF (0) or On (1)
Default OFF (0)
Update rate 4ms write
