Pr 17.26 to Pr 17.34 define the source and destinations for CTNet easy-mode cyclic data.
Identifies which of the EVENT tasks will be scheduled when a CTNet synchronization message is received or generated. This sync. is generated by a
master node (which can be this node) on the CTNet network at a fixed time-base. The following values are defined:
17.32 CTNet easy mode set-up - Transfer slot 1 destination parameter
Digitax ST Variant Plus
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 to 9,999
Default 0
Update rate 4ms write
17.33 CTNet easy mode set-up - Transfer slot 2 destination parameter
Digitax ST Variant Plus
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 to 9,999
Default 0
Update rate 4ms write
17.34 CTNet easy mode set-up - Transfer Motion Processor destination parameter
Digitax ST Variant Plus
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 to 9,999
Default 0
Update rate 4ms write
Parameter Format Channel Description
Pr 17.26 NNNSS 1
Defines the destination node number and slot
NNN = Node number (0-255)
SS = Slot number (1-3)
e.g. A value of 201 means node ID 2, slot 1.
Pr 17.27 MMPP 1
Defines the source drive parameter which is to be transmitted
MM = Menu number
PP = Parameter number
e.g. A value of 302 means Pr 3.02 (speed)
Pr 17.28 NNNSS 2 Destination node number and slot for channel 2
Pr 17.29 MMPP 2 Source drive parameter for channel 2
Pr 17.30 NNNSS 3 Destination node number and slot for channel 3
Pr 17.31 MMPP 3 Source drive parameter for channel 3
Pr 17.32 MMPP 1 Slot 1 destination parameter for incoming data
Pr 17.33 MMPP 2 Slot 2 destination parameter for incoming data
Pr 17.34 MMPP 3 Motion Processor destination parameter for incoming data
17.35 CTNet sync event task ID
Digitax ST Variant Plus
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range Disabled (0), Event (1), Event1 (2), Event2 (3), Event3 (4)
Default Disabled (0)
Update rate 4ms write
