Data read from Pr 90.23
The data in the parameter at address zero is 0x1234.
Bit 15 Bit 14 Bit 13 Data
0x8000 1 0 0 0x00 Address
0x8012 1 0 0 0x12 Data
0x8034 1 1 0 0x34 Data
