Convotherm OEB 10.10 Installation Manual

Technical data, dimensional drawings and connection diagrams
Installation manual 107
► Technical data for accessories
Dimensions
The following table lists the dimensions of accessories for the combi steamer:
Model OES / OGS / OEB / OGB
Appliance size 6.10 6.20 10.10 10.20 12.20 20.10 20.20
W x D x H W x D x H W x D x H W x D x H W x D x H W x D x H W x D x H
[mm] [mm] [mm] [mm] [mm] [mm] [mm]
Open oven stand
without wheels
807 x 700
x 620
1217 x 792
x 620
807 x 700 x
620
1217 x 792
x 620
Open oven stand
with wheels
908 x 700
x 620
1318 x 792
x 620
908 x 700 x
620
1318 x 792
x 620
Enclosed oven
stand without
wheels
810 x 726
x 621
1220 x 818
x 621
810 x 726 x
621
1220 x 818
x 621
Enclosed oven
stand with wheels
908 x 726
x 621
1318 x 818
x 621
908 x 726 x
621
1318 x 818
x 621
Loading trolley
740 x 910 x
1317
535 x 753 x
1853
740 x 910 x
1853
Plate banquet trolley
740 x 977 x
1320
511 x 781 x
1848
740 x 977 x
1320
Extractor hood
905 x 1160
x 414
1190 x
1385 x 414
905 x 1160
x 414
1190 x 1385
x 414

Convotherm OEB 10.10 Specifications

General

Model	OEB 10.10
Capacity	10 x 1/1 GN
Power Supply	Electric
Cooking Modes	Convection, Steam, Combination
Voltage	400 V
Frequency	50/60 Hz
Temperature Range	30°C to 300°C
