Connecting up the combi steamer
Installation manual 51
► Water drain
Water drain regulations
You must comply with local and national regulations on the water drain system and on the composition
of the waste water. In particular these include:
DIN 1988 parts 2 and 4
DIN EN 1717
Local waste water regulations
Safety overflow
The safety overflow (connection diagram: point M) is located underneath the combi steamer. It allows
a permanent connection of the water drain to a drainpipe.
The safety overflow is used to drain away water in the event of a fault. If water is running out of the
safety overflow, check that the water drain is not blocked. Remove any blockages.
Drain connection
The following points must be observed when connecting the drain outlet:
The drain outlet is located underneath the combi steamer (connection diagram: point C).
There must be no restriction or reduction in the cross-section of the drain pipe.
The drain pipe must have a minimum slope of 5 % (3°).
If more than one appliance is connected to one drain pipe, this pipe must be large enough to allow
the waste water to flow out unchecked.
Drain connection for table-top appliances
The drain should preferably be connected permanently using a fixed rigid pipe.
Caution:
When using a funnel waste trap to connect to the drain, this must not be installed under the combi
steamer. Fit the funnel waste trap beside or behind the combi steamer.
