Connecting up the combi steamer
Installation manual 50
Appliance connection
Connect the combi steamer to a cold water supply, which must be of drinking water quality. Warm
water up to a temperature of 40°C can be supplied to the soft water connection. The flow pressure
must equal 2 - 6 bar (3 - 6 bar with CONVOClean system).
The appliance water connection is located underneath the combi steamer (connection diagram: point A
and B). Fit protective filters.
Installing the water supply
Follow the steps below to provide the water supply to your combi steamer:
Step Action
1 Find out the water quality and water hardness from your local water supply company. If necessary,
provide suitable water treatment measures.
Information on the required fresh water quality are given in the "Technical Data" on page 87 section.
2
Flush through the customer's water supply pipe.
3
Install the required water filters and water treatment equipment (X, W, V).
4
Fit a separate shut-off device (Y) with dirt filter for each appliance.
5
Connect the appliance to the pressure hose as shown in the connection diagram.
6
Inform the user of the service intervals for the filters and water treatment equipment.
7
Flush out the filter system.
8
Once the water supply has been installed, close the shut-off device.
Further information
The following sources provide information on the water supply for your combi steamer:
Water circuit diagram behind the motor cover
DIN 1988
DIN EN 61770
