Convotherm OEB 10.10 Installation Manual

Technical data, dimensional drawings and connection diagrams
Installation manual 108
8.2 Dimensions, dimensional drawings and connection diagrams
Purpose of this chapter
This chapter contains the dimensions, dimensional drawings and connection diagrams for your combi
steamer.
Contents
This chapter contains the following topics:
Page
OES/OEB 6.10 109
OES/OEB 6.20 110
OES/OEB 10.10 111
OES/OEB 10.20 112
OES/OEB 12.20 113
OES/OEB 20.10 114
OES/OEB 20.20 115
OGS 6.10 116
OGS 6.20 117
OGS 10.10 118
OGS 10.20 119
OGS 12.20 120
OGS 20.10 121
OGS 20.20 122
OGB 6.10 123
OGB 6.20 124
OGB 10.10 125
OGB 10.20 126
OGB 12.20 127
OGB 20.10 128
OGB 20.20 129

Convotherm OEB 10.10 Specifications

General

Model	OEB 10.10
Capacity	10 x 1/1 GN
Power Supply	Electric
Cooking Modes	Convection, Steam, Combination
Voltage	400 V
Frequency	50/60 Hz
Temperature Range	30°C to 300°C
