Technical data, dimensional drawings and connection diagrams
Installation manual 97
► Technical data for OGS
Dimensions and weights
The following table shows appliance dimensions and weights:
OGS 6.10 6.20 10.10 10.20 12.20 20.10 20.20
Table-top applian-
ces
Floor-standing
appliances
Width including loading trolley
with packaging [mm] 1130 1410 1130 1410 1435 1150 1435
without packaging [mm] 932 1217 932 1217 1232 947 1232
Depth including loading trolley
with packaging [mm] 950 1175 950 1175 1200 1000 1200
without packaging [mm] 805 1027 805 1027 1055 855 1055
Height including loading trolley
with packaging [mm] 1040 1105 1310 1330 1650 2185 2185
without packaging [mm] 852 895 1120 1120 1416 1952 1952
Weight including loading trolley
with packaging [kg] 157 216 183 267 339 350 459
without packaging [kg] 131 179 156 229 286 307 403
Weight with ConvoClean system including loading trolley
with packaging [kg] 163 221 188 272 344 355 467
without packaging [kg] 136 184 161 234 291 312 408
Safety clearances
Rear [mm] 50 50 50 50 50 50 50
Right-hand side [mm] 50 50 50 50 50 50 50
Left-hand side* [mm] 50 50 50 50 50 50 50
Above** [mm] 500 500 500 500 500 500 500
* a larger gap is recommended for servicing purposes
** for ventilation
Maximum permissible loading weight
The following table shows the maximum permissible loading weight per combi steamer. These values
are based on the condition that each shelf can take a maximum load of 15 kg:
Maximum permissible loading
weight
6.10 6.20 10.10 10.20 12.20 20.10 20.20
GN (containers, shelf-grills, baking
trays)
per combi steamer [kg] 30 60 50 100 120 100 180
per shelf [kg] 15 15 15 15 15 15 15
600 x 400 tray (containers, shelf-
grills, baking trays)
with packaging [kg] 30 60 50 100 120 100 180
without packaging [kg] 15 15 15 15 15 15 15
