Convotherm OEB 10.10 Installation Manual

Technical data, dimensional drawings and connection diagrams
Installation manual 98
Electrical installed load ratings
The following table shows the electrical installed load ratings:
OGS 6.10 6.20 10.10 10.20 12.20 20.10 20.20
Table-top applian-
ces
Floor-standing
appliances
3N~ 400V 50/60Hz (3/N/PE)
Rated power consumption [kW] 1,1 1,1 1,1 1,4 1,4 2,1 2,1
Rated current [A] 2,5 2,5 2,5 3,2 3,2 4,7, 5,0
Fuse [A] 16 16 16 16 16 16 16
recommended conductor
cross-section*
[mm
2
] 5G2.5 5G2.5 5G2.5 5G2.5 5G2.5 5G2.5 5G2.5
3~ 230V 50/60Hz (3/PE)
Rated power consumption [kW] 1,3 1,3 1,3 1,7 1,7 2,5 2,6
Rated current [A] 4,5 4,5 4,5 5,8 5,8 8,7 9,0
Fuse [A] 16 16 16 16 16 16 16
recommended conductor
cross-section*
[mm
2
] 5G2.5 5G2.5 5G2.5 5G2.5 5G2.5 5G2.5 5G2.5
*recommended conductor cross-section for wires laid uncovered in air up to 5 m in length.
Gas supply
The following table shows the values for the gas supply:
6.10 6.20 10.10 10.20 12.20 20.10 20.20
Table-top applian-
ces
Floor-standing
appliances
Fuels Natural gas, liquid gas
Flue gas connection Air conditioning system with safety shutdown
Gas consumption
The following table lists the gas consumption of the gas appliances:
6.10 6.20 10.10 10.20 12.20 20.10 20.20
Natural gas (H) G20
[m
3
/h]
1,3 2,1 2,1 3,7 4,2 4,2 7,4
Natural gas (L) G25
[m
3
/h]
1,5 2,5 2,5 4,3 4,9 4,9 8,6
Liquid gas G30/G31*
[kg/h]
0,9 1,5 1,5 2,7 3,1 3,1 5,4
* up to 15% higher consumption for butane G30

Convotherm OEB 10.10 Specifications

General

Model	OEB 10.10
Capacity	10 x 1/1 GN
Power Supply	Electric
Cooking Modes	Convection, Steam, Combination
Voltage	400 V
Frequency	50/60 Hz
Temperature Range	30°C to 300°C
