Connecting up the combi steamer
Installation manual 47
► Energy optimization system
Meaning
You can connect the combi steamer to an energy optimization system (e.g. SICOTRONIC). An energy
optimization system smoothes out peaks in power consumption that occur during operation of your
appliances, and can thereby help to reduce your energy costs.
Terminals for connecting to an energy optimization system
The combi steamer is connected to an energy optimization system via isolated contacts.
The terminals (B) and (C) of the X10 terminal block are isolated contacts. The X10 terminal block is
located behind the left-hand removable side wall. The position of terminals (B) and (C) is shown in the
circuit diagram.
Requirements
The energy optimization system is de-energized.
Installing an energy optimization system
Follow the steps below to connect your combi steamer to an energy optimization system:
Step Action
1
Refer to the circuit diagram and operating instructions of the energy optimization system.
2
Remove the wire link between the terminals (B) and (C) on the X10 terminal block.
3
Connect the terminals (B) and (C) of the X10 terminal block to the energy optimization system.

Convotherm OEB 10.10 Specifications

General

Model	OEB 10.10
Capacity	10 x 1/1 GN
Power Supply	Electric
Cooking Modes	Convection, Steam, Combination
Voltage	400 V
Frequency	50/60 Hz
Temperature Range	30°C to 300°C
