Convotherm OEB 10.10 Installation Manual

For your safety
Installation manual 28
No. Safety device Function Check
6
(no picture)
Magnetic door switch:
electrical door sensor in
appliance door
Switches off the fan and heater
when the appliance door is opened
Check magnetic door switch at low
temperature:
Action
 Open the appliance door fully
 Press Start
Result
Motor must not start up
7
(no picture)
Emergency opening in
appliance door;
Prevents anyone being
locked inside the oven
accidentally
Appliance door in the on-latch
position:
Allows the appliance door to be
pushed open from the inside after
shutting the door.
Check at low temperature:
put the appliance door in the on-
latch position (see Opening the
appliance door safely in the user
manual)
Action
From the outside, pull forcefully on
the top left of the appliance door
Result
The appliance door must open.
8
(no picture)
Automatic rinsing after
power failure in case
cleaning agent left in
combi steamer
Re-starts fully automatic cleaning
(CONVOClean system) in a de-
fined state after power failure
This test is a software function.
There is no need for the operator
to perform a test.
9
(no picture)
Spray-guard
Stops the cleaning agent being
injected during fully automatic
cleaning (CONVOClean system)
when the appliance door is opened
Prompt to close the appliance door
The operability of the magnetic
door switch is checked by the
software at the beginning of each
cleaning program
10
Preheat bridge
Prevents scalding from escaping
steam when the loading trolley is
not in the floor-standing appliance
during preheating
See
Inserting and removing the pre-
heat bridge (floor-standing appli-
ances only) in the user manual for
further details
11 (installed
by customer)
Disconnection device
Installed by the customer close to
the appliance; easily visible and
accessible, 3-pole action, minimum
contact separation 3 mm.
Used to disconnect the appliance
from the power supply during
cleaning, repair and maintenance
work and in case of danger.
Action
 Trip the disconnection device.
 Check at the X10 terminal strip
on the appliance that there is no
voltage at all three poles.
12 (installed
by customer)
Gas shut-off device
Installed by customer close to
appliance in easily accessible
position and clearly labeled.
Used to disconnect the appliance
from the gas supply during clean-
ing, repair and maintenance work
and in case of danger.
Action
 Close gas shut-off device.
 Check that the appliance is
isolated from the gas supply.

Convotherm OEB 10.10 Specifications

General

Model	OEB 10.10
Capacity	10 x 1/1 GN
Power Supply	Electric
Cooking Modes	Convection, Steam, Combination
Voltage	400 V
Frequency	50/60 Hz
Temperature Range	30°C to 300°C
