Convotherm OEB 10.10 Installation Manual

Technical data, dimensional drawings and connection diagrams
Installation manual 90
Water supply
The following table shows the values for the water supply:
6.10 6.20 10.10 10.20 12.20 20.10 20.20
Table-top applian-
ces
Floor-standing
appliances
Water supply (cold only)
Shut-off device with non-return valve (type EA) and dirt filter
Water supply
without ConvoClean
system
G 3/4'', permanent connection optional with min. DN 10 supply pipe
with ConvoClean system G 3/4'', permanent connection optional with min. DN 10 supply pipe
Flow pressure
without ConvoClean
system
[kPa]
200 - 600 (2 - 6 bar)
with ConvoClean system
[kPa]
300 - 600 (3 - 6 bar)
Water drain*
Type
DN
50 50 50 50 50 50 50
* Permanent connection (recommended) or funnel waste trap
Water quality
The following table shows the values for the water quality:
Demoisturization, injection,
cleaning
Condenser, hand shower
Drinking water quality (install water treatment unit if necessary)
Total hardness
(German degrees of
hardness)
[°dH]
4 - 7 4 - 20
(French degrees of
hardness)
[TH]
7 - 13 7 - 27
(English degrees of
hardness)
[°e]
5 - 9 5 - 19
[ppm]
70 - 125 70 - 270
[mmol/l]
0,7 - 1,3 0,7 - 2,7
Temperature (T)
[°C]
max. 40 max. 40
Conductivity
[µS/cm]
min. 20 min. 20
pH 6,5 - 8,5 6,5 - 8,5
Cl-
[mg/]l
max. 100 max. 100
SO
4
2-
[mg/l]
max. 150 max. 150
Fe
[mg/l]
max. 0.1 max. 0.1

Convotherm OEB 10.10 Specifications

General

Model	OEB 10.10
Capacity	10 x 1/1 GN
Power Supply	Electric
Cooking Modes	Convection, Steam, Combination
Voltage	400 V
Frequency	50/60 Hz
Temperature Range	30°C to 300°C
