ABS 2.0 Operator’s Manual
Publication Number: 621058590OPR - 4 - © 2019, Cornelius Inc.
INTRODUCTION
SYSTEM OVERVIEW
The Automated Beverage System ABS 2.0 is an upgraded version of ABS. The ABS 2.0 is designed for drive-
thru area installation or other restricted area that is accessible to authorized personnel only. When a beverage is
ordered from the P.O.S. register, the ABS 2.0 automatically drops a cup, fills it with ice and dispenses the correct
amount and type of any syrup-based beverage. The finished drink is then moved by the conveyor to the pick-up sta-
tion and the drink description is displayed on the touchscreen.
Operation of the ABS 2.0 is restricted to employees and service personnel that have been trained and certified
in t
he proper operation, service and maintenance of the equipment.
SPECIFICATION
Table 1. Product Specification
Unit Dimen-
sions
Length 911.86 mm [35.9 inch]
Width 901.70 mm [35.5 inch]
Height 1905 mm [75.0 inch]
Unit weight
Dry weight 267.62 Kg [590 lbs] (Dry)
Operational weight
(With ice, water, etc.)
362.87 Kg [800 lbs]
Cooling
met
hod
Method of product
cooling
Cold plate & on board chiller for condition “C”
Ice storage
ca
pacity
W/o bin extender 61.24 Kg [135 lbs]
Electrical
Line voltage
621058590: 115 ± 10% VAC, 60 Hz, 1 Phase
621058773: 220-240 VAC, 50-60 Hz, 1 Phase
Current 3A
Connection method
115V/60Hz (North America): IEC-NEMA 5-15P
220-240V, 50-60Hz (Rest of World): TBD
Water
Supply pressure 0.55 Mpa [80 psi] static
Supply method 12.7 mm [1/2 inch] ID tube (Python)
Syrup
Supply pressure 0.45 Mpa [65 psi] Optimal
Supply method 9.52 mm [3/8 inch] ID tube (Python)
Temperature
Water & Syrup Max 1.7°C (35°F) Water & 3.33°C (38°F) Syrup
Ambient Operating
Tempe
rature
18°C (65°F) to 35°C (95°F)
Air and CO
2
Supply pressure
CO
2
/Compressed Air: 0.55 ± 10% Mpa
[80 ± 10% psi]
Supply method 9.52 mm [3/8 inch] ID tube
Clearance
Re
quirement
Top
No ice Maker:1905mm [75 inch] + 304.8 mm [12 inch]
ref
ill area = 2209.8 mm [87 inch]
With ice Maker: 2501.9 mm [98.5 inch]
Back 50.8 mm [2 inch] clearance to wall (min)
