Viper Low overrun Service Manual
© 2016, Cornelius Inc - 21 - Publication Number: 621360241LOEWSE
When the sleep and wakeup settings are complete, press the BACK button to save the settings and return to the
Select menu, shown in Figure 13.
Setting Defrost Lockout
From the Barrel Status menu, shown in Figure 8, press the MENU button and then press the SETUP button to dis-
play the Setup menu. Use the up and down arrows on the right of the control to highlight the Events Setup menu,
then press GO to enter the menu (Figure 16).
The lockout can also be set day by day or for all days with up to three lockout periods of four hours each per day.
These lockout periods may be overlapped to provide from four to 12 hours of defrost lockout, if desired. When the
periods are overlapped, it is recommended that the defrost lockouts for sequential lockout periods be overlapped
by 15 minutes. The defrost lockout affects all barrels in the unit. To set the defrost lockouts, perform the procedure
in Table 17.
When the defrost lockout settings are complete, press the BACK button to save the settings and return to the
Select menu, shown in Figure 13.
5 Set hour field
Use the left and right arrows to select the hour field
and press the + or - buttons to change the hour.
6 Set minute field
Use the left and right arrows to select the minute
field and press the + or - buttons to change the
minutes (15 min. increments)
7 Select AM/PM field
If the 12 hour clock option is selected, use the left
and right arrows to select the AM/PM field. Then
press the + or - buttons to change between AM and
PM.
8 Select DAY for Wakeup Repeat Steps 2 and 3 as needed.
9 Select WAKEUP
Use the up and down arrows to highlight WAKEUP
and repeat Steps 5 through 7 to set the WAKEUP
times.
Table 17.
Step Action Procedure
1 Set defrost lockout Open Events Setup menu, shown in Figure 16
2 Select DAY The DAY field is highlighted.
3Set DAY
Use the + and - buttons at the bottom of the display
to set the desired day or all days.
4 Select DEFROST LOCK 1
Use the up and down arrows to highlight
DEFROST LOCK 1.
5 Set hour field Use left and right arrows to select hour field
6
Use the + and - buttons at the bottom of the display
to set the desired hour.
7 Set minute field Use left and right arrows to select minute field
8
Use the + and - buttons at the bottom of the display
to set the desired minute (in 15 min. increments).
9 Select AM/PM field
If the 12 hour clock option is selected, use the left
and right arrows to select the AM/PM field.
10
Use the + button at the bottom of the display to set
the AM/PM field.
11 Select DEFROST LOCK 2
Repeat Steps 2 through 10 for the DEFROST
LOCK 2 time, if desired.
12 Select DEFROST LOCK 3
Repeat Steps 2 through 10 for the DEFROST
LOCK 3 time, if desired.
Table 16.
Step Action Procedure
