Viper Low overrun Service Manual
© 2016, Cornelius Inc - 43 - Publication Number: 621360241LOEWSE
Table 44.
Step Action
1. Turn the Product/BRIX valve to the Product position.
2.
Manually open the manual water flow valve to start filling the barrel with wash
water. At the same time, open the faceplate relief valve until water comes out.
3.
From the Barrel Status menu, press the SPIN button while highlighting the
appropriate barrel. This starts the scraper blade. Allow the blade to operate for
fifteen seconds, then turn barrel OFF by pressing the OFF button.
4. To drain the water from the system, turn the barrel OFF.
5.
Place a container under the barrel dispensing valve. Open the dispensing
valve and dispense all rinse water from the barrel. When the pressure in the
barrel drops, from the Barrel Maintenance menu, press the PURGE button to
re-pressurize the barrel with CO
2. As the wash water level lowers in the barrel,
partially close the valve to avoid spurting.
6.
Remove the sanitizing fitting (p/n cc 28688) from the BIB connector and con-
nect a BIB containing syrup to the syrup line.
7.
Rotate the Product/BRIX valve to the BRIX position and open the valve at the
end of the tube.
8.
Hold a waste container under the BRIX tube to collect the sanitizing solution
from the syrup line and open the manual syrup flow valve to start filling the
syrup line with syrup. Continue to hold open the syrup flow valve until syrup
starts coming out of the BRIX tube.
9. Perform a BRIX setup. See “BRIX Setup Menu” on page 28.
10. Fill the barrel with product as described in Table 22.
11. Perform motor calibration. See “Calibrating a Motor” on page 32.
