FIGURE 21: CARDBOARD REMOVAL
3.
Hammer off the wood furring strips by hitting
on the inside of the side panels Figure 22.
CAUTION
Be careful not to damage the cover components
and other parts in the crate.
Flatten all protruding nails.
FIGURE 22: REMOVE CARDBOARD AND STRIPS
4.
Remove the C- channels, U- frames, the
escape hatch box, the hardware boxes, the
foam pieces and the contour seal from the
crate. Temporarily put these items in a safe
location see Figure 23.
FIGURE 23: REMOVE COMPONENTS FROM CRATE
ID DESCRIPTION
A C-CHANNEL AND U-FRAME
B CONTOUR SEAL
C HARDWARE BOX
D ESCAPE HATCH BOX
E HARDWARE BOX
240799 OWNER'S MANUAL REVISION 4
