Kangaroo™ Console | 9
Section II: Assembly and Initial Administrator Use
Assembling System Parts
Attach battery:
The battery provided is both removable and rechargeable. To place it into the console, align it with the space on the
back, then lightly press it in.
Attach mounting clamp (optional):
The console can be attached to a vertical pole using the mounting clamp, included with the systemcomponents.
Attach the clamp to the console by aligning the hole on the pole clamp with the mounting hole on the back of the
console. Use a 3/8” - 16 bolt to fasten together.
Attach the mounting clamp to a pole by fitting it in between. Then, tighten the knob so that the clamp and console
are securely attached.
Connecting power adapter:
The removable power adapter connects to the console to charge the battery.
To connect, arrow on power adapter should be facing up (same side asscreen).
To disconnect, grasp cord by the locking sleeve and pull away from console.
