149
Dimensions (HxWxD)
39.4 x 23.6 x 10.24 in. (1000×600×260mm)
Weight
Inverter:123.5lbs/56kg; Wirebox:33lbs/15kg
Mounting / Installation
Angle
4
15 to 90 degrees from horizontal
(vertical, or angled)
AC Termination
M8 Stud Type Terminal Block
(Wire range: #6-3/0AWG CU or #6-3/0AWG AL) Lugs not supplied
DC Termination
Screw Clamp, Neg. Busbar (RSD version) Wire range: #14 - #6AWG CU
Fused String Inputs
(2/5 per MPPT)
15A standard fuse value (Fuse values up to 30A acceptable)
Safety
PV Arc-Fault Circuit
Protection
Type 1
Safety and EMC
Standard
UL 1741, CSA C22.2 No. 107.1; UL 1699B; FCC Part 15
Grid Standard and SRD
IEEE 1547, IEEE 1547.1, UL 1741SA(Rule 21 ); HECO (Rule 14)
Smart-Grid Features
Voltage-RideThru, Frequency-RideThru, Soft-Start, Volt-Var, Frequency-Watt,
Volt-Watt
3) See Chapter 3.1 for further requirements regarding non-operating conditions.
4) See Chapter 3.2 for Shade Cover accessory requirement for installation angles of 75 degrees or less.
