CPS SCA Series - Appearance and Main Item Description

11
 Fixed Power Factor – deactivated
 Reconnect by “Soft-Start” Methods – activated
 Frequency-Watt – activated
 Volt-Watt – activated
 Set Active Power Function Mode (Optional) – activated under mutual
agreement
 Dynamic Reactive Power Support Mode (Optional) – activated under
mutual agreement
2.5 Appearance and Main Item Description
2
8
5 6 7
1
3
4
9
Figure 2-2 Diagram of the Inverter Assembley
