154
20%
40%
60%
80%
100%
Po/Pn
0.88*Un Un 1.06*Un 1.1*Un
Grid Voltage (Vac)
volt-watt function enable
Figure 10-3-2 SCA25/50/60KTL-DO/US Derating Curve of Grid Voltage
