79
Grid Connection Rule
IEEE1547
CA Rule 21
HECO-HM
HECO-ML
ISO-NE
Only for CPS SCA50/60KTL-DO/US-480
Figure 6-6 Setting Grid Rule
3. PV Input Mode. This allows the user to read the inverter working
mode as “Independent" or "Parallel" mode. The inverter is factory set
in Independent mode. If this needs to be set to Parallel contact CPS to
have this setting changed.
4. Neutral Line Setting. This option allows the user to select “Yes/No” if
a neutral conductor has been connected to the inverter. This setting
INSTRUCTION:
Please check with your local electric utility supply company before
selecting a grid standard. If the inverter is operated with an incorrect
grid standard, the electric utility supply company may cancel the
interconnection agreement.
Placing the inverter into operation before the overall system complies
with the national codes, rules and safety regulations of the
application is also not permitted.
