Control Command
Factory Defaults
ARC Detect
Force Restart
ARC Clear
P1/2
Control Command
P2/2
PV1 PV2
PV3
Time
Vmppt(V)
Pmppt(kW)
Udc(V)
Idc(A)
0
0 0
0.0
0.0
0.0
0.0
0.0 0.0
0.0 0.0
0.0
MPPT Scan
Figure 6-8 Control Command Setting
1. Force Restart. If a fault shutdown happens, a severe fault may have
occurred inside the inverter. The user can perform a force reboot for
one time in this menu if the user needs to restart the inverter.
2. Factory Default. The manufacturer’s parameter default values can be
restored when the inverter is not in operation mode. Otherwise “Fault
Operated” will be reported.
3. ARC Detect. Mannually begin an arc-fault test. The inverter will cease
power production and test ARC.
Arcing check and protection is mainly divided into two parts, the Arcing
check board is responsible for whether there is Arcing in line, and
transfer an Arc protection signal to the DSP in the dominating control
INSTRUCTION:
Force Restart is effective only when the faults “IntFault0010~0150” in
the troubleshooting table occur. The inverter may restore to normal
operation automatically if alarm or protection faults occur. This
function will not respond when the inverter is in operation mode and a
“FaultOperated” alarm interface will be indicated.
To Next Page
