ASSEMBLY
Installing the Back Rail to the Table
Insert the square head bolts (5/16-18 x 1”) into the holes on the back of the saw
table and extension tables.
Take the flanged hex nut (5/16-18) loosely allowing the square bolt head to
protrude just a little.
Now, slide the back rail slot just over each of the square head bolts and at this
point only finger tighten.
See Figure 8
