ASSEMBLY
Mounting the Motor Assembly
You will need to mount the motor to the back of saw. To do so, first loosen the 2
hex head screws that lock the pins in the mounting brace. At this point, insert the
2 pins on the motor assembly into the holes on the mounting brace. Push it in as
far as it will go. At this point, DO NOT tighten the screws.
See Figure 16
Figure 16
