PARTS LISTING – MITER GAUGE ASSEMBLY
NO.
PART
NUMBER
DESCRIPTION
QTY
1 TH1006 MITRE GAUGE ASSEMBLY 1
2 TH100606 HANDLE 1
3 HU190400 WASHER 8.5*23*2.0 1
4 TH100601 MITRE GAUGE 1
5 HU150100 HEX.NUT #6-32NC 3
6 HU040101 SCREW #8-32NC*5/16" 1
7 TH100604 ANGLE INDEX 1
8 TH100603 INDICATOR BLOCK 1
9 TH100605 LOCK ROD/PIN 1
10 HU030101 SET SCREW M5*0.8P*5 1
11 HU040604 SCREW #6-32NC*5/8" 3
12 TH030303 LEAD PLATE 1
13 HU050101 SCREW M6*1.0P*6 1
14 TH100602 PLATE 1
15 HU050102 SCREW M6*1.0P*20 1
16 HU200100 STAR WASHER 4.3*8.5(BW-4) 2
17 HU040104 SCREW #8-32NC*5/8" 2
18 TH100607 ANGLE INDEX RULE 1
19 HI010105 ROUND NUT 2*5 2
