PARTS LISTING – MOTOR ASSEMBLY
1 TH3303 MOTOR SET ASSEMBLY 1
2 HU150500 NUT 5/16"-18NC 4
3 HU200400 STAR WASHER 8.4*15 4
4 TH100014 MOTOR BASE 1
5 HU070101 SCREW 5/16"-18NC*1/2" 4
6 HU230100 E RING ETW-8 2
7 TH100017 SPRING 1
8 TH1012 MOTOR SUPPORT SET 1
9 TH100045 SLEEVE 1
10 HU190300 WASHER 6.7*19*1.0 1
11 HU060101 SCREW 1/4"-20NC*5/8" 1
12 TH100015 HINGE PIN 1
13 HU140203 SET 5/16"-18NC*1/2" 1
14 TH100064 BELT 1
15 HU290101 KEY 5*5*18 1
16 TH100085 MOTOR 1
17 JE0B0C01 SWITCH 1
18 HU090101 SCREW #10-32NF*3/8" 3
19 TH100047 SWITCH BOX 1
20 HN031000 STRAING RELIEF SB8R-1 2
21 TH100089 CORD WITH PLUG 1
22 HU150200 NUT #10-32NF 2
23 HU130101
STAR WASHER #10-32NF*3/8"
2
24 HU180100 NUT #10-32NF 2
25 PG1A0N06 GROUNDING LABELS 2
26 TH330002 SWITCH PLATE 1
27 HU200200 STAR WASHER 5.3*10 2
28 TH100088 CORD 1
29 TH1011 BELT GUARD ASSEMBLY 1
30 TH100066 BELT PLATE 1
31 TH100067 BELT COVER 1
32 HU170100 NUT M5*0.8P 4
33 JE0B0C03 SWITCH KEY 1
34 HU191300 WASHER 5.3*12*1.0 4
35 TH100903 VOLTAGE LABEL 1
36 TH100901 MOTOR NAME PLATE
