14 • DGE-100 and DM-DGE-200-C Product Manual — Doc. 7696D
IR/Serial 1-way device control via infrared up to 1.1MHz or serial TTL/RS-232 (0–5V) up
to 19200 baud (via control system)
HDMI HDCP 1.4, EDID, CEC
Pointing Device Support
Compatible with the TSD-2220 touch screen display and most third-party USBHIDcompliant touch
screens, mice, and keyboards
Streaming Decoder
Video Formats H.264 (MPEG-4 part 10 AVC), MJPEG
Audio Formats AAC stereo
Bitrates Up to 25Mbps
1
Resolutions Up to 1080p60
Video
Input Signal Types HDMI (DVI and dual-mode DisplayPort™ signal compatible
4
)
Output SignalTypes HDMI (DVI compatible
4
)
Input Resolutions 640x480@60Hz, 720x480@60Hz (480p), 720x576@50Hz (576p),
800x600@60Hz, 848x480@60Hz, 852x480@60Hz, 854x480@60Hz,
1024x768@60Hz, 1024x852@60Hz, 1024x1024@60Hz, 1280x720@50Hz
(720p50), 1280x720@60Hz (720p60), 1280x768@60Hz, 1280x800@60Hz,
1280x960@60Hz, 1280x1024@60Hz, 1360x768@60Hz, 1365x1024@60Hz,
1366x768@60Hz, 1400x1050@60Hz, 1440x900@60Hz, 1600x900@60Hz,
1600x1200@60Hz, 1680x1050@60Hz, 1920x1080@24Hz (1080p24),
1920x1080@25Hz (1080p25), 1920x1080@50Hz (1080p50), 1920x1080@60Hz
(1080p60), plus any other resolution allowed by HDMI up to 148MHz pixel clock
NOTE: Interlaced video is not supported
Output Resolutions 640x480@60Hz, 800x600@60Hz, 1024x768@60Hz
5
, 1280x720@50Hz
(720p50), 1280x720@60Hz (720p60), 1280x800@60Hz
5
, 1366x768@60Hz
5
,
1440x900@60Hz
5
, 1600x900@60Hz
6
, 1600x1200@60Hz, 1680x1050@60Hz
5
,
1920x1080@50Hz (1080p50), 1920x1080@60Hz (1080p60), 1920x1200@60Hz
Audio
Input Signal Types HDMI (dual-mode DisplayPort compatible
4
)
Output SignalTypes HDMI
Input/Output Formats 2 channel LPCM
Audio Feedback
Formats
MP3
Connectors
CONSOLE(USB) (1) USB Micro A connector, female;
USB computer console port;
Type A to Micro AUSBcable included
