Crestron DGE-100 User Manual

Product Manual — Doc. 7696D DGE-100 and DM-DGE-200-C • 15
IR1–2 (1)4-pin 3.5mm detachable terminal block;
Comprises (2)IR/serial ports;
IRoutput to 1.1 MHz;
1-way serial TTL/RS-232 (0–5V) up to 19200 baud
COM (1) 5-pin 3.5mm detachable terminal block;
Bidirectional RS-232 port;
Up to 115.2k baud, hardware and software handshaking support
HDMIINPUT (1) HDMIType Aconnector, female;
HDMIdigital video/audio input;
DVI and dual-mode DisplayPort signal compatible
4
HDMIOUTPUT (1)HDMIType Aconnector, female;
HDMI digital video/audio output;
DVI compatible
4
USB (1)USBType Aconnector, female;
USB 2.0 host port for connecting a USBHIDcompliant touch screen, mouse, or
keyboard
LANPoE (1)8-pin RJ-45 connector, female;
100BASE-TX Ethernet port;
Power over Ethernet (PoE)compliant
24VDC 0.75A (1)2.1 x 5.5mm DCpower connector;
24VDCpower input;
PW-2407WUpower pack included
G (1) 6-32 screw;
Chassis ground lug
Controls and Indicators
PWR (1) Green LED, indicates operating power is present via the local power pack or
PoE(Power over Ethernet);
Flashes while the device is booting
RESET (1) Recessed push button for hardware reset
SETUP (1)Red LEDand (1)recessed push button for Ethernet setup
ONLINE (1)Green LED, indicates a connection is established to a control system via
Ethernet
HDMIIN/OUT (2)Green LEDs, indicate the presence of an HDMIsignal at the HDMIinput or
output, respectively
LANPoE (1)Green LED and (1)amber LED;
Green LEDindicates the Ethernet link status;
Amber LEDindicates Ethernet activity
Power
PoE(Power over
Ethernet)
IEEE 802.3at Type 1 (802.3af compatible) Class 0 (12.95W) PoE Powered
Device
Power Pack (Included) Input:100–240VAC, 50/60Hz;
Output:0.75A@ 24VDC;
Model:PW-2407WU

Crestron DGE-100 Specifications

General

Brand	Crestron
Model	DGE-100
Category	Engine
Language	English
