Product Manual — Doc. 7696D DGE-100 and DM-DGE-200-C • 19
DigitalMedia™
Technology
DM8G+, HDCP 2.2, EDID, Ethernet, PoDM(Power over DM®)sourcing
HDMI, Input HDCP 1.4, EDID, CEC
2
HDMI, Output HDCP 2.2, EDID, CEC
2
Pointing Device Support
Compatible with the TSD-2220 touch screen display and most third-party USBHIDcompliant touch
screens, mice, and keyboards
Streaming Decoder
Video Formats H.264 (MPEG-4 part 10 AVC), MJPEG
Audio Formats AAC stereo
Bitrates Up to 25Mbps
4
Resolutions Up to 1080p60
Video
Input Signal Types DM8G+, HDMI (DVI and dual-mode DisplayPort™ signal compatible
11
)
Output SignalTypes HDMI (DVI compatible
11
)
Maximum Input
Resolutions
Input Type Scan Type Resolution Frame Rate Color Sampling Color Depth
DM 8G+®
Progressive
4096x2160 DCI 4K or 3840x2160 Ultra HD
24 Hz 4:4:4 30 bit
30 Hz 4:4:4 24 bit
30 Hz 4:2:2 36 bit
60 Hz 4:2:0 24 bit
2560x1600 WQXGA 60 Hz 4:4:4 36 bit
1920x1080 HD 1080p 60 Hz 4:4:4 36 bit
Interlaced 1920x1080 HD 1080i 30 Hz 4:4:4 36 bit
HDMI® Progressive 1920x1080 HD 1080p 60 Hz 4:4:4 36 bit
NOTE: Common input resolutions are provided in the table above. Other custom input resolutions are
supported at pixel clock rates up to 300 MHz for the DM 8G+ input, or 148 MHz for the HDMI input.
Interlaced video is not supported via the HDMI input.
Output Resolutions 1920x1080@60Hz (1080p60), 3840x2160@30Hz (4K UHD)
NOTE: All video inputs are scaled automatically to the operative output resolution when displayed full
screen.
Audio
