20 • DGE-100 and DM-DGE-200-C Product Manual — Doc. 7696D
Input Signal Types DM8G+, HDMI (dual-mode DisplayPort compatible
11
)
9
Output SignalTypes HDMI
DMInput Formats Up to 8 channel LPCM
HDMIInput Formats 2 channel LPCM
HDMIOutput Formats Up to 8 channel LPCM
Audio Feedback
Formats
MP3
Connectors
CONSOLE(USB) (1) USB Micro A connector, female;
USB computer console port;
Type A to Micro AUSBcable included
IR1–2 (1)4-pin 3.5mm detachable terminal block;
Comprises (2)IR/serial ports
1
;
IRoutput to 1.1 MHz;
1-way serial TTL/RS-232 (0–5V) up to 19200 baud
COM (1) 5-pin 3.5mm detachable terminal block;
Bidirectional RS-232 port
1
;
Up to 115.2k baud, hardware and software handshaking support
LAN (1)8-pin RJ-45 connector, female;
100BASE-TX Ethernet port
HDMIINPUT (1) HDMIType Aconnector, female;
HDMIdigital video/audio input
9
;
DVI and dual-mode DisplayPort signal compatible
11
HDMIOUTPUT (1)HDMIType Aconnector, female;
HDMI digital video/audio output
9
;
DVI compatible
11
USB (1)USBType Aconnector, female;
USB 2.0 host port for connecting a USBHIDcompliant touch screen, mouse, or
keyboard
DMIN (1)8-pin RJ-45 connector, female;
DM8G+input
3,5,8,9
, PoDMPSE(Power over DMPower Sourcing Equipment)
port
24VDC 0.75A (1)2.1 x 5.5mm DCpower connector;
24VDCpower input;
PW-2420RUpower pack included
G (1) 6-32 screw;
Chassis ground lug
Controls and Indicators
PWR (1) Green LED, indicates operating power is present via the local power pack;
Flashes while the device is booting
RESET (1) Recessed push button for hardware reset
SETUP (1)Red LEDand (1)recessed push button for Ethernet setup
