Product Manual — Doc. 7696D DGE-100 and DM-DGE-200-C • 21
LAN (1)Green LED and (1)amber LED;
Green LEDindicates the Ethernet link status;
Amber LEDindicates Ethernet activity
ONLINE (1)Green LED, indicates a connection is established to a control system via
Ethernet
HDMIIN/OUT (2)Green LEDs, indicate the presence of an HDMIsignal at the HDMIinput or
output, respectively
DMIN (1)Green LED and (1)amber LED;
Green LEDindicates the DM link status;
Amber LEDindicates video and HDCPsignal presence
Power
Power Pack (Included) Input:1.5A(maximum)@100–240VAC, 50/60Hz;
Output:2A@ 24VDC;
Model:PW-2420RU
Power Consumption 24W (typical, without a PoDMPDconnected)
PoDM(Power over
DM)Sourcing
IEEE 802.3at Type 1 compliant PoDM PSE (Power Sourcing Equipment),
supplies up to 15.4 W (Class 0–3) to power one PoDM PD (Powered Device)
Environmental
Temperature 32° to 104°F (0° to 40°C)
Humidity 10% to 90% RH (noncondensing)
Heat Dissipation 81.9BTU/hr
Enclosure
Chassis Metal, black finish, (2)integral mounting flanges, vented sides
Mounting Freestanding, surface mount, or attach to a single rack rail
Dimensions
Height 7.93in. (203mm)
Width 9.29in. (236mm)
Depth 1.36in. (35mm)
Weight
25.6oz (726g)
Compliance
Regulatory Model: DM-DGE-200-C;
UL® Listed for US and Canada, IC, CE, FCC Part 15 Class B digital device
To search for product certificates, refer to support.crestron.com/app/certificates.
