Crestron SIMPL™ Windows Software
Network Analyzer
Overview
The Crestron Network Analyzer is an application designed for advanced users. It is
intended to be a diagnostic tool used to identify problems within a network.
Crestron Network Analyzer
The Crestron Network Analyzer has been developed to assist system programmers
and installation technicians in diagnosing electrical problems in the systems network
wiring.
By graphing voltage levels and time, the Network Analyzer will help identify the
following problems:
• Problem network devices
• Voltage drops
• Electrical shorts
• Breaks in network wires or miswired network devices
Using Network Analyzer
This section will review the necessary procedures to start Network Analyzer, acquire
new files, and open existing ones.
Installation & Operations Guide – DOC. 5728C Crestron SIMPL Windows • 129
