Crison 44 - Instrument Composition

10
General information
Figure 3 Door detail
2.3 Instrument composition
The MULTIMETER 44 is a modular instrument that can be configured with 1, 2 or 3
channels. The instrument can be delivered complete with 3 channels or the number of
channels can be extended as needed.
* To be completed with 1, 2 or 3 measuring boards
NOTICE
The instrument protection IP 65 is only ensured with the door closed and connector MP-5
protected. For Panel Mounting instruments, see
3.3 Panel mounting, page 15
*
IP 65
2.3.1 Base module
Description Code
MultiMeter 44, base instrument*, 220 V.
44 00
MultiMeter 44, base instrument*, 24 V
44 01
2.3.2 Additional communication
Description Code
RS 485 interface installed on MultiMeter 44
...485
PROFIBUS DP output installed on 44
...pro
2.3.3 Measuring boards
See instrument and measuring boards specifications in the corresponding chapter of the
manual.
Description Code
Measuring board: pH/mV + Temperature 44 10
Measuring board: Conductivity + Temperature 44 20
Measuring board: D.O. (membrane) + Temperature 44 30
Measuring board: D.O. (optical) + Temperature 44 40
Measuring board: Chlorine (galvanic) + Temperature 44 50
Measuring board: Chlorine (membrane) + Temperature 44 60
