Operation
See Calibration procedure, page 25
Note: During calibration with standards, the relays assigned to the corresponding channel stay
deactivated. The 4-20 mA outputs (register) are in Hold (21 mA or last value).

*Channel 2 and 3 activated. This message appears when Individual Hold (sensors installed in
different places) is programmed. 
The configuration of set Hold means relays deactivation of all channels during calibration with
standards of any of the sensors.
4.7.3.1 Manual, indirect calibration
Readjustment of the measured value. For this purpose, previously the oxygen
concentration should have been measured using perfectly calibrated instrument.
The readjustment can be performed in any of the measuring units.
1. From the main menu select CALIBRATE. Confirm.
2. Select the channel to calibrate and confirm.
3. Select MANUAL CALIBRATION and confirm.
Note: The calibration data introduction do not provoke any change in relays and 4-20 mA output.
The cleaning relay is deactivated during manual, indirect calibration.
4. Adjust the measured value using the keypad.
5. Press OK to accept calibration.
4.7.3.2 Reset Calibration
Performing of calibration reset and going back to the factory values.
1. From the main menu select CALIBRATE. Confirm.
2. Select the channel and confirm.
3. Select RESET CALIBRATION and confirm.
Note: To measure is important any out calibration in air or manual calibration.
4.7.4 Measurement
The concentration of the dissolved oxygen mg/L and the temperature appear on the
display.
Temperature readjustment, see detailed information on 4.16, Page 54.
DO measurement in % of saturation
It is necessary to select the corresponding units.
4.8 D.O. Channel (optical sensor)
4.8.1 Connections
DANGER
Always disconnect power to the instrument when making any electrical connections.
DANGER
Relays: Limit the current up to 3A by using one fuse. Do not connect cables with voltage higher
than 24 V.
