Page 25
as Day Zones to output #1. Zones are defined as Day Zones at P453E/P454E and P473E/P474E.
Day zones are those which operate only during periods when the Area is disarmed and are normally
used as door bells and shop minders etc.
Option 8 Spare
Note: P282E through P288E are as above but apply to outputs 2-8 for Area A
Note: P382E through P388E are as above but apply to outputs 2-8 for Area B
Note: P482E through P488E are as above but apply to outputs 2-8 for Area C
PARTITION “A,B & C” SPECIFIC OUTPUT OPTIONS
PARTITION "A" -
P291E - P298E
PARTITION "B"
- P391E - P398E
PARTITION "C"
- P491E - P498E
The addresses above allow a number of secondary Area based options to be assigned to any of the 8 outputs.
Address P291 relates to Output 1 options for Area A, address P391 relates to Output 1 options for Area B and
address P491 relates to Output 1 options for Area C.
P291E 1E
Any exclude to output #1
2E Auto-Exclude warning to output #1
3E Entry beeps to output #1
4E Exit beeps to output #1
5E Control function to output #1
6E Arm indication to output #1
7E Stay Mode Arm indication to output #1
8E Disarm indication to output #1
Option 1 Any exclude to output #1 - This option will produce a change of state at output #1 if there are any
zones excluded, either manually or automatically. This change of state will occur at the end of the
Exit delay. The output reset time (P551E) should be set to zero when this option is enabled.
Option 2 Auto-Exclude warning to output #1 - This option will produce a 2 second pulse at output #1 at the
end of the exit period if a zone has been Auto-excluded in Area "A". An Auto-Exclude occurs when a
zone is left un-sealed at the end of the exit delay. At the end of the exit delay zones not defined as
Auto-Exclude which are left un-sealed will produce an activation. Auto-Exclude assignments are
found at P447E and P467E
Option 3
Entry beeps to output #1
- This option will map the keypad entry beeps to output #1.
Option 4 Exit beeps to output #1 - This option will map the keypad exit beeps to output #1.
Option 5 Control function to output #1 - This option maps the control functions in Area "A" to output #1.
Control function parameters for Area "A" are defined at P301E options 5-8
Option 6 Arm indication to output #1 - This option will turn output #1 on when Area "A" is armed and turn
output #1 off when Area "A" is disarmed. This change of state occurs at the start of the exit delay
and when the Area is disarmed. Output reset time should be set to zero (P551E 0E)
Option 7 Stay Mode Arm indication to output 1 - This option will turn output #1 on when Area "A" is placed
in Monitor Mode and turn output #1 off when Area "A" Monitor Mode is turned off. Like option 6 this
change of state occurs either at the start of the exit delay or when the Area is disarmed. Output reset
time should be set to zero (P551E 0E)
Option 8 Disarm indication to output #1 - This option will turn output #1 on when Area "A" is disarmed either
from Full Arm or Stay Mode and turn output #1 off when Area "A" is Armed or in Stay Mode. Like
option 6 this change of state occurs either at the start of the exit delay or when the Area is disarmed.
Output reset time should be set to zero (P551E 0E)
Note: P292E through P298E are as above but apply to outputs 2-8 for Area A
Note: P392E through P398E are as above but apply to outputs 2-8 for Area B
A OptB O/P 1
1 2 - - - - - -
