P273E 1-8E Keypads with buzzer mapped to Pendant “Panic” Alarm
(Default 1-8)
If the LED is On, a radio Pendant Panic alarm will cause the buzzer at the keypad to sound.
P274E 1-8E Keypads with buzzer mapped to keypad “Panic” or “(1 & 3)” Alarm (Default 1-8)
If the LED is On, a Keypad Panic alarm will cause the buzzer at the keypad to sound.
P275E 1-8E Keypads with buzzer mapped to keypad “Fire” (4 & 6) Alarm (Default 1-8)
If the LED is On, a Keypad Fire alarm will cause the buzzer at the keypad to sound.
P276E 1-8E Keypads with buzzer mapped to keypad “Medical” (7 & 9) Alarm (Default 1-8)
If the LED is On, a Keypad Medical alarm will cause the buzzer at the keypad to sound.
P277E 1-8E Keypads with buzzer mapped to phone line failure (Default none)
If the LED is On, a Telephone Line Failure will cause the buzzer at the keypad to sound.
Pressing any button will silence the beep.
P278E 1-8E Keypads with facility to turn the LED's off after Exit Delay (Default none)
If the LED is On, the Zone & System LED’s on an LED keypad will turn off when all areas
assigned to the keypad are Armed or in Stay mode. On an LCD keypad, the LCD and the
keypad button backlighting will turn off when Armed or in Stay Mode. The LED’s and
backlighting will automatically turn on again if there is an alarm, an entry delay is started, any
button is pressed at the keypad or when the system is Disarmed.
PARTITION “A,B & C” PRIMERY OUTPUT OPTIONS
PARTITION "A" -
P281E - P288E
PARTITION "B" -
P381E - P388E
PARTITION "C" -
P481E - P488E
The addresses above allow a number Area based options to be assigned to any of the 8 outputs. Address P281
relates to Output 1 options for Area A, address P381 relates to Output 1 options for Area B and address P481
relates to Output 1 options for Area C.
P281E 1E Normal zone alarms to output #1
2E Stay Mode alarms to output #1
3E Pendant chirps to output #1
4E All zones sealed indication to output #1
5E 2 second pulse on arming or disarming to output #1
6E Spare
7E Day zone alarms to output #1
8E Spare
Option 1
Normal zone alarms to output #1
- This option will map activation from normal zone alarms from
Area "A" to output #1. Normal zones are those which will only activate when the partition is armed
(Set)
Option 2
Stay Mode alarms to output #1
- This option will map activations from zones defined as Area "A" Stay
Mode to output #1. Zones are defined as being in Stay Mode at P445E and P465E
Option 3
Pendant Chirps to output #1
- This option will map two short pulses (Chirps) to output #1 when Area
"A" is set via a radio key (Pendant) and four short pulses to output #1 when Area "A" is unset again.
The length of the pulses (Chirps) are set by the pulse timer for this output.
Option 4 All zones sealed indication to output #1
- This option will map an Area "A" “Ready” indication to
output #1. A “Ready” indication is produced when all zones in an area are sealed, i.e. zone lights off.
Option 5
2 second pulse to output #1 on arming or disarming
- This option will map a 2 second pulse to
Output #1 each time Area "A" is armed or disarmed as defined at P302E options 6&7.
Option 6 Spare
Option 7 Day zone alarms (Chime) to output #1 - The option will map activations from Area "A" zones defined
Leds Off when Idel
- - - - - - - -
1 2 - - - - - -
A OptA O/P 1
To Next Page
