Page 33
open circuit on the input in this configuration will be seen as both the low and high zones in
alarm. Finally, if this option is on and zone doubling is on for the same input the 2k2 resistor
must be fitted in conjunction with the 4k7 and 8k2 resistors. In this mode, a short or open circuit
on the input will be seen as a zone tamper alarm.
LOW ZONE ASSIGNMENTS
ZONES 1-8
P441E - P460E
Combinations of options in addresses P441E to P460E may be used to give the most suitable zone behaviour.
P441E 1-8E
Zone is in Area "A"
- Where options 1-8 represent zones 1-8. This option assigns a zone to
Area "A" within a partitioned system. If the system is not partitioned, all zones must be assigned
to Area "A". (Default all in Area "A") See P310E8E also.
P442E 1-8E
Zone is in Area "B"
- Where options 1-8 represent zones 1-8. This option assigns a zone to
Area "B" within a partitioned system. (Default none in Area "B") See P310E8E also.
If a zone is defined in both Area "A" and Area "B" it is deemed to be in Area "C"
P443E 1-8E Zone is a normally open input - where options 1-8
represent zones 1-8. This option is u s e d w h e n
normally open detectors such as smoke detectors are to
connected to a zone. The option only applies if zone
doubling is turned On at P410E. Default is all zones
normally closed.
P444E 1-8E
Zone is a radio detector
- Where options 1-8 represent zones 1-8. This option is used when
Radio (wireless) devices are used as detectors. (Default none)
P445E 1-8E Stay Mode Zones - Where options 1-8 represent zones 1-8. Zones included at this address will
become active when the panel is in Stay Mode. Zones not assigned at this address will be
excluded. (Default 1-4) Note: Stay Mode Zones are linked to Area assignments
P446E 1-8E Zone can be Bypassed - Where options 1-8 represent zones 1-8. This option determines if a
zone can be Bypassed either manually or via the Auto-Bypass process. (Default all on)
P447E 1-8E Auto Bypass Zones - Where options 1-8 represent zones 1-8. Zones assigned Auto Bypass
function at this address will be automatically bypassed by the system if they are unsealed when
the exit timers expire. Zones not given Auto Bypass status will cause an activation if they are
unsealed at the end of the exit delay period. (Default all on)
P448E 1-8E Zone is a handover - Where options 1-8 represent zones 1-8. Zones defined at this address as
handover are given the unique ability to behave as both delay and instant zones. If a zone
defined as an entry delay zone has been activated and the entry delay is running, a handover
zone will behave as another entry delay zone with a delay time as defined at P511E to P526E.
If an entry delay zone has not been activated and there is no entry delay running, a handover
zone becomes an instant zone with no entry delay. The Handover zone MUST have an entry
delay programmed.
Area B Zones 1-8
Zone is a handove
- - - - - - - -
- - - - - - - -
