Page 53
P588E
1-4E
Zone 8 Bypass mapped to Scenario 1-4
- Default 1
P589E 1-4E Zone 9 Bypass mapped to Scenario 1-4 - Default 1
P590E 1-4E Zone 10 Bypass mapped to Scenario 1-4 - Default 1
P591E 1-4E Zone 11 Bypass mapped to Scenario 1-4 - Default 1
P592E
1-4E
Zone 12 Bypass mapped to Scenario 1-4
- Default 1
P593E 1-4E Zone 13 Bypass mapped to Scenario 1-4 - Default 1
P594E 1-4E Zone 14 Bypass mapped to Scenario 1-4 - Default 1
P595E
1-4E Zone 15 Bypass mapped to Scenario 1-4 -
Default 1
P596E 1-4E Zone 16 Bypass mapped to Scenario 1-4 - Default 1
LOW ZONE TAMPERS SCENARIO MAPPING
P601E - P608E
This group of addresses is used to map the eight possible low zone tampers to one of the four possible reporting sce-
narios. If a value of zero (0) is assigned at an address in this block, low tampers from that zone will not be reported
by the panel. Low Zone Tamper is a short circuit input.
P601E
1-4E
Short Circuit Tamper Alarm on Input 1 mapped to Scenario 1-4
- Default 1
P602E 1-4E Short Circuit Tamper Alarm on Input 2 mapped to Scenario 1-4 - Default 1
P603E 1-4E Short Circuit Tamper Alarm on Input 3 mapped to Scenario 1-4 - Default 1
P604E 1-4E Short Circuit Tamper Alarm on Input 4 mapped to Scenario 1-4 - Default 1
P605E
1-4E
Short Circuit Tamper Alarm on Input 5 mapped to Scenario 1-4
- Default 1
P606E 1-4E Short Circuit Tamper Alarm on Input 6 mapped to Scenario 1-4 - Default 1
P607E 1-4E Short Circuit Tamper Alarm on Input 7 mapped to Scenario 1-4 - Default 1
P608E
1-4E
Short Circuit Tamper Alarm on Input 8 mapped to Scenario 1-4
- Default 1
HIGH ZONE TAMPERS SCENARIO MAPPING
P609E - P616E
This group of addresses is used to map the eight possible High zone tampers to one of the four possible reporting
scenarios. If a value of zero (0) is assigned at an address in this block, high tampers from that zone will not be re-
ported by the panel. High Zone Tamper is an open circuit input.
P609E 1-4E Open Circuit Tamper Alarm on Input 1 mapped to Scenario 1-4 - Default 1
P610E 1-4E Open Circuit Tamper Alarm on Input 2 mapped to Scenario 1-4 - Default 1
P611E 1-4E Open Circuit Tamper Alarm on Input 3 mapped to Scenario 1-4 - Default 1
P612E
1-4E
Open Circuit Tamper Alarm on Input 4 mapped to Scenario 1-4
- Default 1
P613E 1-4E Open Circuit Tamper Alarm on Input 5 mapped to Scenario 1-4 - Default 1
P614E 1-4E Open Circuit Tamper Alarm on Input 6 mapped to Scenario 1-4 - Default 1
P615E
1-4E
Open Circuit Tamper Alarm on Input 7 mapped to Scenario 1-4
- Default 1
P616E 1-4E Open Circuit Tamper Alarm on Input 8 mapped to Scenario 1-4 - Default 1
SYSTEM EVENTS SCENARIO MAPPING
P421E - P438E
This group of addresses is used is used to map System Events as listed below to one of the four possible reporting
scenarios. If a value of zero (0) is assigned at an address in this block, that event will not be reported by the panel.
P421E Area A Arm/Disarm reports mapped to scenario 1-4 default 1
P422E Area B Arm/Disarm reports mapped to scenario 1-4 default 1
P423E Area C Arm/Disarm reports mapped to scenario 1-4 default 1
P424E Keypad Panic (& buttons 1 & 3) mapped to scenario 1-4 default 1
P425E Keypad Fire (buttons 4 & 6) mapped to scenario 1-4 default 1
P426E Keypad Medical (buttons 7 & 9) mapped to scenario 1-4 default 1
P427E Battery low mapped to scenario 1-4 default 1
P428E Mains fail mapped to scenario 1-4 default 1
P429E Phone line restore mapped to scenario 1-4 default 1
P430E Radio PIR battery low mapped to scenario 1-4 default 1
P431E Radio-key battery low mapped to scenario 1-4 default 1
P432E Keypad tamper mapped to scenario 1-4 default 1
Zone 1 bypass Sc
1
Area A Scenario
1
