Page 66
option 3 at P6176E is off the outputs will latch on and must be reset by a valid user code. Only user
codes with option 7 on at address P4E can reset a Global Egress input. If option 3 is on the outputs will
reset as soon as the input seals.
ACCESS CONTROL OPTIONS B
Access Control Options B - P6176E 1-64E
The behaviour of an access control zone can be modified with these options.
Option 1 = Report Access violations as the output # not zone #
Option 2 = Hide this zone on the web status page
Option 3 = Zone restore auto-resets Egress Outputs
Option 1 Report Access violations as the output # not zone # - When a zone is associated with an output at
P6174E and the zone is set as an access Door Monitor (option 1 at P6175E) it will report door access
violations to monitoring as the zone that triggered the event. If this option is turned on it will report the
access violations as the programmed output number at P6174E.
Option 2 Hide this zone on the web status page - If this option is turned on the zone will not appear on the
status page of the web interface.
Option 3 Zone restore auto-resets Egress Outputs - If option 3 is turned on and the zone is set as an Egress
type (options 3, 4, & 5 at P6175E) then the output/s will stay on while the input is open but they will
automatically turn off when the input seals. If option 3 is off the Egress output/s must be reset by a valid
user code (option 7 on at P4E)
ACCESS “DOOR OPEN TOO LONG” BEEPS to KEYPADS
Access Door Open Too Long Beeps to Keypads - P6177E 1-64E Value = 01-32 for Keypads 1-32
If a zone set as an Access Door Monitor triggers a “Door Open Too Long” alarm state this option allows any keypad
to annunciate that alarm. The alarm will auto-reset when the input seals.
ACCESS “DOOR FORCED” OPEN BEEP to KEYPADS
Access Door Forced Open Beeps to Keypads - P6178E 1-64E Value = 01-32 for Keypads 1-32
If a zone set as an Access Door Monitor triggers a “Door Forced” alarm state this option allows any keypad to
annunciate that alarm. The alarm will auto-reset when the input seals.
ACCESS “DOOR OPEN TOO LONG” to OUTPUTS
Access Door Open Too Long to Outputs - P6179E 1-64E Value = 01-32 for Outputs 1-32
If a zone set as an Access Door Monitor triggers a “Door Open Too Long” alarm state this option allows any Output
to indicate that alarm. The alarm will auto-reset when the input seals.
ACCESS “DOOR FORCED” OPEN to OUTPUTS
Access Door Forced Open to Outputs - P6179E 1-64E Value = 01-32 for Outputs 1-32
If a zone set as an Access Door Monitor triggers a “Door Forced” alarm state this option allows any Output to indicate
that alarm. The alarm will auto-reset when the input seals.
+++++Time Zones+++++
HOLIDAYS
HOLIDAYS - P170E 1-32E (DDMMYY)
It is possible to pre-program up to 32 holidays. Holidays can override the time-zone function on the programmed day.
For example, if an output was automatically controlled by a time-zone, the pre-programmed holidays can stop the
output from turning on or off on a holiday. A holiday consists of a single day programmed by Date/Month/Year
(DDMMYY). The holiday begins at the start of the day (00:00:00) and finishes immediately before midnight (23:59:59)
on the programmed date. Holidays can be programmed in any order (although for simplicity it is recommended that
they are programmed in chronological order) and the panel automatically removes them once the day ends. If you
wish to manually remove a programmed holiday you must program in 000000 at the holiday location. If the holiday
date you are attempting to enter is older than the current date the panel will not save the data eg if the current date
