Page 18
FULL LCD KEYPAD TEXT EDITING
The FUL LCD keypad has various text locations that allow for customising of names that will appear when viewing
events in memory mode. For example all of the 2000 users can have a unique 20 character name. All LCD Text edit-
ing is done in the “Installer Program Mode” at the main control panel. A list of the text that can be customised when in
Installation Program mode is as follows;
Program LCD KP “User “Name
P16E 1-2000E Program LCD KP “User” Name Text
LCD KP “Idle” Display Name
P25E 14E This location is where the LCD KP “Idle” Display Name can be Programmed.
Program LCD KP “Output” Name
P31E 1-32E Program LCD KP “Output” Name Text
Program LCD KP “Area” Name
P69E 1-32E Program LCD KP “Area” Name Text
Program LCD KP “Keypad” Name
P100E 1-32E Program LCD KP “Keypad” Name Text
Program LCD KP ” Zone” Name
P169E 1-64E Program LCD KP “Zone” Name Text
When in Installer Program Mode and at one of the above program locations the arrow buttons can be used.
The “MEMÇ” or the “È” buttons can be used to change between upper (Capital) and lower case letters. The “Å” or
“Æ” buttons can be used to move the cursor left or right to the letter you wish to change.
In the chart below the main characters are those selected when set to Upper case (Capital) mode. The characters in
brackets are those selected when in lower case mode.
▼Button # 1st Press 2nd Press 3rd Press 4th Press
1 * (‘) # (<) = (>) 1
2 A (a) B (b) C (c) 2
3 D (d) E (e) F (f) 3
4 G (g) H (h) I (i) 4
5 J (j) K (k) L (l) 5
6 M (m) N (n) O (o) 6
7 P (p) Q (q) R (r) 7
8 S (s) T (t) U (u) 8
9 V (v) W (w) X (x) 9
0 Blank Y (y) Z (z) 0
