Property Configuration
Energisation Either Normally Energised or Normally De-
EnergisedThe default is Normally De-Energised.
Table 13: Relay output types
Note that in the diagrams below, for all output types other than Pulsed and Reset Pulse, the On and Off
Delay times are presumed to be zero.
Latching:
The relay output is
trueACCEPT/RESE
T is pressed after the
alarm condition has
cleared.
You can program
the ON and OFF
delays.
Non-latching
The relay output is
true while the alarm
condition is true.
ACCEPT/RESET
has no effect.
You can program
the ON and OFF
delays.
