Dimension
VA 500 Bi-directional English 1.24 Seite 22 von 56
9 Dimension
416,0 (Standard Schaft 220mm)
76,5

(ISO 228/1)
SW 32
SW 27
75,0
220 mm(Standard)
Optional: 120, 160, 300, 400 mm
Ø11,7
Connector plug A
Connector plug B
