CS Instruments VA 500 - Network Settings Static IP

^ Operation
VA 500 Bi-directional English 1.24 Seite 39 von 56
11.3.2.2.2 Network Settings static IP
Settings → Network Setup Settings → IP Address → IP Address
Settings → Network Setup Settings → IP Address → Sub Netz
Settings → Network Setup Settings → IP Address → Gateway
For manual (static) IP, the "IP Address",
"Subnet" and "Gateway" selection keys must
be selected and activated with "OK".
The first data field of the selection, in this case
the IP address, is then marked (red).
Confirm with "OK” the corresponding input menu
is opened.
By means of ">", the next data field is changed.
Select the desired position with the ">" key and
activate it with the "OK" key.
Change the values with the ">" key, and accept
the values with the "OK" key.
Procedure for "Subnet" and "Gateway" is
analogous.
Store the settings by „Save“
