^ Operation
VA 500 Bi-directional English 1.24 Seite 40 von 56
11.3.2.2.3 Modbus TCP Settings
Settings → Network Setup Settings → IP Address
→
MB TCP
Settings → Network Setup Settings → IP Address
→
ID
Settings → Network Setup Settings → IP Address
→
Port
For changes, e.g. the sensor ID,
first select by pressing key „>“ the field “ID” and
then key “OK”.
Select the desired position by pressing the ">"
and select with "OK" button.
Change values by pressing the „>“ values
takeover by pressing "OK".
Input for the port is done analogue.
By means of the button "Byte Format" it is
possible to change the data format (Word Order).
Possible formats are "ABCD" (Big Endian) and
"CDAB" (Middle Endian)
Saving the changes by pressing "Save",
therefore select it with key „>“ and then confirm
it with "OK".
Reset to the default settings by activating "Set to
Default"-
