^ Operation
VA 500 Bi-directional English 1.24 Seite 30 von 56
11.3.1 Sensor Setup
Setup → Sensor Setup
53.1 mm
11.3.1.1 Input / change tube diameter
Settings → Sensor Setup→ Diameter
.
For changes, first select the menu item
with key „ “ and then confirm it with
“OK“.
In order to change, e.g. the unit, first select
by pressing key „ “ the field “Units” and
then key “OK”.
Select with the key „ “ the correct unit and
then confirm selection by pressing 2x „OK“.
Entering / changing the diameter
via button „“ , select the respective position
and activate the position with the "OK"
button.
By pressing „“ the position value is
incremented by 1. Complete with "OK" and
activate next number position.
Confirm entry by pressing „OK“.
