Transport and practical equipment
Store the rear shelf
Fig. 106
In the luggage compartment: covers for
storing the rear shelf.
Fig. 107 In the luggage compartment: fitting the
rear shelf.
Depending on the equipment, once the lug-
g
ag
e compartment shelf has been removed,
it can be stored under the boot floor.
●
Remove the left and right covers
›››
Fig. 106.
●
Place the rear shelf in the corresponding
housing
›››
Fig. 107.
●
Put the left and right covers in their original
position.
Variable luggage compartment floor
Fig. 108
Variable luggage compartment floor:
raised position;
lowered position.
Fig. 109 Variable luggage compartment floor: in-
clined position.
Variable floor in high position
●
To move from the low position to the high
po
sition, lift the floor using the handle
›
››
Fig. 108
1
, and pull it back until the front
of the floor has fully passed the supports
2
.
●
Move the floor forward over the supports
as f
ar as the r
ear seat backrest and then low-
er the floor with the handle
1
.
V
ariable floor in lo
w position
●
To move from the high position to the low
position, lift the floor using the handle
›››
Fig. 108
1
, and pull it back until the front
of the floor has fully passed the supports
2
.
●
Now let the front part fall to the floor and
slide the floor f
orw
ards as far as the rear seat
backrest; lower the floor at the same time
with the handle
1
.
»
127
