User Guide DDOC0099-000-AH
DTS1 CSfC A - 4 Specifications
© 2020 Curtiss-Wright Defense Solutions Revision 3.0
A.2 DTS1 Specifications
Physical Dimensions
Height............................................................ 1.50 In. (38.1 mm) chassis
Width ............................................................. 5.00 In. (127.0 mm) chassis
Depth............................................................. 7.99 In. (202.9mm) knob to GND lug.
Weight:
Without RMC Module .................................... 2.60 lb. (1.18 kg)
Power
Input Power ................................................... 28 VDC (MIL-STD 704E)
Power Dissipation ......................................... 4 Watts average with RMC
Peak Inrush Current ...................................... 1.3 Amps
A.3 RMC Module Specifications
RMC Module Physical Dimensions
Height............................................................ 0.66 In. (16.76 mm)
Width ............................................................. 3.000 + 0.22 In.rails (76.20 mm +5.59 mm rails)
Depth............................................................. 5.000 + 0.390 In. knob (27.0mm +9.9 mm knob)
Weight ........................................................... 0.7 lb. (0.317kg)
* RMC module weight dependent on configuration. Weight provided is maximum weight for any
RMC module configuration.
Reliability
Data Reliability .............................................. <1 non-recoverable error in 10
14
bits read.
Data Retention .............................................. >10 years.
SSD Endurance ............................................ >100,00 writes
Capacity
128 GB (unformatted) ................................... 117 GB (formatted)
256 GB (unformatted) ................................... 235 GB (formatted)
512 GB (unformatted) ................................... 470 GB (formatted)
1 TB (Unformatted) ....................................... 931 GB (formatted)
2 TB (Unformatted) ....................................... 1.862 TB (formatted)
4 TB (Unformatted) ....................................... 3,725 TB (formatted)
A.4 Mean Time Between Failures
These Mean Time Between Failure (MTBF) values (provided in hours) were calculated using
Windchill Quality Solutions Relex 2011 software with MIL-HDBK- 217 FN2, Calculation model and
the environmental factors listed.
Table A.1 DTS1 / RMC Calculated Mean Time Between Failures
Order Number MTBF
VS-DTS1SL-F (L-Bracket Mounting)
VS-DTS1SL-FD (DZUS Panel Mounting)
Ground Benign / Controlled @ 20
°C
190,004
Ground Mobile @ 30
°C
15,382
Naval Sheltered @ 20
°C
28,208
Airborne Uninhabited Cargo @ 30
°C
10,300
Airborne Uninhabited Fighter @ 30
°C
7,729
Airborne Rotary Wing @ 30
°C
5,432
