B.2 Utility Connector J2 / Utility Lab Cable
Table B.3 provides DTS1 bulkhead J2 connector pin signals. Figure B.3 show the DTS1 bulkhead
J2 connector pinout. Table B.4 shows the DTS1 utility lab cable connection pin signals. Figure B.4
show the utility lab cable wiring diagram.
Connector Manufacturer Glenair
Connector Reference DesignatorJ2
Connector.........PN 801-023-07M9-19PA
Mating ConnectorPN 801-007-16M9-19SA
Table B.3 Utility Connector J2 Signals
Connector
Pin Signal Name Signal Type Direction Description / Functions
1
ZEROIZE_N Analog
In
Active low open collector/switch closure to
induce Zeroization of DTS. This signal must
be active for a minimum of 5 seconds for
the zeroization process to take affect.
2
RST_IN_N Analog
In
Active low external reset input. Short to
GND to invoke DTS reset.
3
GND Analog
Signal return/GND for ZEROIZE_N and
RST_IN_N
4
GND Analog NC
5
NASP_RXD RS-232
In
NAS Processor Serial Port Receive I/F
6
GND Analog
Signal return/GND for NASP_RXD and
NASP_TXD
7
BI_DA1- GbE
In / Out
Gigabit Ethernet Bi-directional pair A1+/-
8
BI_DD1+ GbE
In / Out
Gigabit Ethernet Bi-directional pair D1+/-
9
GND Analog NC
10
NASP_TXD RS-232
Out
NAS Processor Serial Port Transmit I/F
11
GND Analog NC
12
BI_DA1+ GbE
In / Out
Gigabit Ethernet Bi-directional pair A1+/-
13
BI_DD1- GbE
In / Out
Gigabit Ethernet Bi-directional pair D1+/-
14
GND Analog NC
15
GND Analog NC
16
BI_DB1- GbE
In / Out
Gigabit Ethernet Bi-directional pair B1+/-
17
BI_DC1+ GbE
In / Out
Gigabit Ethernet Bi-directional pair C1+/-
18
BI_DC1- GbE
In / Out
Gigabit Ethernet Bi-directional pair C1+/-
19
BI_DB1+ GbE
In / Out
Gigabit Ethernet Bi-directional pair B1+/-
